Description

Burkard : Computer Controlled Spraying Apparatus

This apparatus was designed to meet the more exacting requirements of the modern toxicology labs, but is equally suitable for most laboratory spray application requirements. Sprays may be accurately applied to a wide range of target shapes and sizes as defined by the computer programme selected. Tests with aqueous media, sprayed onto 9cm pel:ti dishes, showed good replication of the deposit with over 90% reaching the target.

The apparatus may be used in a standard fume cupboard or an external exhaust system could be fitted. The enclosed liquid reservoir is conveniently placed for easy filling or purging of the system.

Most standard computers with a serial output can be used to drive the unit through a graphics or  WP  software package.

A fully adjustable air pressure reducing valve and pressure gauge are fitted as standard.

For ease of cleaning and to minimise possible contamination or corrosion, essential areas are finished in stainless steel.

                           Technical Specifications

Dimensions WxDxH : 51 x 61 x 40 cm
Maximum working pressure : 20 psi
Capacity of resevoir : 20 ml
Nett weight : Approx 22 kg
